Introduction
Although “rhabdomyosarcoma” was once regarded as a single disease, it has become abundantly clear over the past several decades that they are in fact a family of genetically distinct sarcomas, sharing skeletal muscle differentiation, but differing from each other in important ways. This chapter will first cover general aspects of rhabdomyosarcomas, and then discuss specific rhabdomyosarcoma subtypes.
Arthur Purdy Stout was the first to delineate rhabdomyosarcoma as a distinct entity, and Horn and Enterline devised the first rhabdomyosarcoma classification scheme in 1958. During the 1930s and 1940s, a very large percentage of pleomorphic sarcomas in adults were considered to represent pleomorphic rhabdomyosarcoma, and most of the rhabdomyosarcomas reported during this period were of this type. , These tumors occurred mainly in the muscles of the lower extremity and affected older patients. They displayed a striking degree of cellular pleomorphism, but cells with cross-striations were typically absent. It subsequently became apparent that virtually all of these tumors were other types of pleomorphic sarcoma, including what we now term undifferentiated pleomorphic sarcoma (UPS).
It also became evident that many childhood sarcomas formerly diagnosed descriptively as “round cell” or “spindle cell” sarcomas were rhabdomyosarcomas of alveolar or embryonal type. Knowledge of these tumors was fostered by the introduction of newer, more effective therapies. Before 1960, childhood rhabdomyosarcoma was an almost uniformly fatal neoplasm that recurred and metastasized in a high percentage of cases. During the last several decades, however, it has been shown that this tumor responds to multimodality therapy—encompassing biopsy or conservative surgery, multiagent chemotherapy, and radiotherapy—and that many children treated by these modalities remain free of recurrent and metastatic disease. The numerous reports of the Intergroup Rhabdomyosarcoma Study (IRS) (now recognized as the Soft Tissue Sarcoma Committee of the Children’s Oncology Group) have contributed greatly to our understanding of childhood rhabdomyosarcomas, especially the effect of the various treatment modalities on the survival of patients with this tumor.
The most recent WHO classification recognizes four major rhabdomyosarcoma subtypes: embryonal , alveolar , pleomorphic , and spindle cell/sclerosing. Spindle cell/sclerosing rhabdomyosarcoma is further divided based on specific genetic events, including MYOD1 -mutant, infantile V GLL2/NCOA2/CITED2 -fused, and fusion-driven tumors ( Box 20.1 ). It is anticipated that the classification of rhabdomyosarcoma will only continue to become more complex, as new, clinically relevant, genetically distinct subtypes are identified. Going forward, molecular genetic features, in particular fusion status, will undoubtedly play a much larger role in risk stratification and therapeutic strategies. ,
Box 20.1
Rhabdomyosarcoma Subtypes
-
Embryonal rhabdomyosarcoma
-
Alveolar rhabdomyosarcoma
-
Pleomorphic rhabdomyosarcoma
-
Rhabdomyosarcomas with spindle cell and sclerosing features
-
—MYOD1-mutant spindle cell/sclerosing rhabdomyosarcoma
-
—Infantile fusion-driven spindle cell rhabdomyosarcoma
-
-
Adult fusion-driven spindle cell rhabdomyosarcoma of bone and soft tissue
-
—Adult spindle cell rhabdomyosarcoma, not otherwise specified
-
-
Epithelioid rhabdomyosarcoma
Etiology and Pathogenesis
As with other sarcomas, evidence is lacking to suggest that rhabdomyosarcoma actually arises from skeletal muscle cells. In fact, these tumors often arise at sites where striated muscle tissue is normally absent (e.g., common bile duct, urinary bladder), or scant (e.g., nasal cavity, middle ear, vagina). With the notable exception of rhabdomyosarcomas arising in inflammatory rhabdomyoblastic tumor (a skeletal muscle tumor of borderline malignancy), rhabdomyosarcomas are not known to arise from a precursor lesion.
Little is known about the underlying cause of the rhabdomyoblastic proliferations and the stimulus that induces their growth. Genetic factors are implicated by the rare occurrence of the disease in siblings, the occasional presence of the tumor at birth, and the association of the disease with other neoplasms in the same patient. Rhabdomyosarcoma has been described in conjunction with congenital retinoblastoma, familial adenomatous polyposis, multiple lentigines syndrome, type 1 neurofibromatosis, Costello syndrome, Noonan syndrome, and Beckwith–Wiedemann syndrome, among a host of others. Germline mutations in the DICER1 gene predispose affected patients to a broad range of tumors (DICER1 syndrome), including embryonal rhabdomyosarcoma. A 2009 report from the Children’s Oncology Group found an association between first-trimester x-ray exposure and embryonal rhabdomyosarcoma.
Incidence
Rhabdomyosarcoma is not only the most common soft tissue sarcoma in children under 15 years of age, but also one of the most common soft tissue sarcomas of adolescents and young adults. Rhabdomyosarcoma accounts for an estimated 4.5% of all childhood cancers, with an annual incidence of six cases per 1 million per year. It is rare in persons older than 45 and accounts for an estimated 2%–5% of all adult sarcomas, but it is probably lower than that. There is a bimodal distribution for age at presentation, with the first peak occurring between 2 and 6 years and a second peak between 10 and 18 years. This reflects the peak incidence of embryonal and alveolar rhabdomyosarcomas, respectively.
Age and Gender Distribution
Each of the rhabdomyosarcoma subtypes occurs in a characteristic age group. For example, embryonal rhabdomyosarcomas affect mainly, but not exclusively, children between birth and 15 years of age. On the other hand, alveolar rhabdomyosarcoma tends to affect older patients, with peak ages of 10–25 years. Rhabdomyosarcomas are uncommon in patients older than 40, with the exception of fusion-driven spindle cell tumors of bone (median patient age 41 years) and soft tissue (median patient age 50 years). MYOD1 -mutant spindle cell rhabdomyosarcomas occur roughly equally in the pediatric and adult populations. There is some correlation between tumor location and age; for example, rhabdomyosarcomas of the urinary bladder, prostate, vagina, and middle ear tend to occur at a younger age (median: 4 years) than those in the paratesticular region or the extremities (median: 14 years for both).
Males are affected more often than females by approximately 1.5:1.0, but the male predominance is less pronounced during adolescence and young adulthood and for rhabdomyosarcomas of the alveolar type. Fusion-driven and MYOD1 -mutant spindle cell rhabdomyosarcomas are somewhat more common in women. ,
Clinical Features
Although rhabdomyosarcomas may arise anywhere in the body, they occur predominantly in three regions: the head and neck, genitourinary tract and retroperitoneum, and upper and lower extremities. Each rhabdomyosarcoma histologic subtype may occur in virtually any location, but each subtype has a site predilection, as discussed in the specific sections.
The head and neck area is the principal location of rhabdomyosarcoma; 970 (26%) of 3717 tumors from IRS-I, IRS-II, and IRS-III occurred in this location ( Table 20.1 ). In the head and neck, parameningeal tumors are the most common. Parameningeal rhabdomyosarcomas should be distinguished from other rhabdomyosarcomas arising in the head and neck because of their potential for intracranial extension and seeding, and therefore less favorable clinical course. For purposes of risk-stratification, parameningeal rhabdomyosarcomas are considered TNM stage 2, whereas tumors occurring in the orbit and other head/neck locations are stage 1.
Table 20.1
Anatomic Distribution of Rhabdomyosarcoma from Intergroup Rhabdomyosarcoma Group Studies (IRS-I, IRS-II, IRS-III), 1972 and 1991
Modified from Pappo AS, Shapiro DN, Crist WM, et al. Biology and therapy of pediatric rhabdomyosarcoma. J Clin Oncol . 1995;13:2123.
| Anatomic Location | No. | % |
|---|---|---|
| Head and neck | 970 | 26 |
| Parameningeal | 437 | 12 |
| Miscellaneous sites | 276 | 7 |
| Orbit | 257 | 7 |
| Genitourinary | 650 | 17 |
| Extremities | 511 | 14 |
| Other sites | 616 | 17 |
| Total | 3717 | 100 |
The orbit is the second most common head and neck site of rhabdomyosarcoma, accounting for 7% of cases from the IRS series. Most rhabdomyosarcomas in this location are of the embryonal subtype. , For example, 221 (90%) of 245 orbital tumors from IRS-I through IRS-IV were of the embryonal subtype, although rare botryoid-type embryonal rhabdomyosarcomas and alveolar rhabdomyosarcomas also arise in the orbit. Rhabdomyosarcoma may also involve other head and neck sites, including the nasal cavity and nasopharynx, followed in frequency by the ear and ear canal, paranasal sinuses, soft tissues of the face and neck, and oral cavity (including the tongue, lip, and palate). ,
After the head and neck, the genitourinary tract is the second most common site for rhabdomyosarcoma. In the IRS series, 650 (17%) of 3717 cases arose in this general region. Histologically, most tumors arising in this location are of the embryonal subtype. The most common location is the paratesticular region, often of the embryonal or spindle cell/sclerosing subtypes. They may also involve the spermatic cord and epididymis, but usually are separate from the testis proper.
The retroperitoneum and pelvis are other sites of involvement. Approximately 45% of tumors in these sites are of the embryonal subtype, but up to 15% are alveolar rhabdomyosarcomas. , In general, effective therapy of rhabdomyosarcomas in the retroperitoneum and pelvic region is more difficult than that of paratesticular rhabdomyosarcomas.
Approximately 5% of rhabdomyosarcomas arise in the urinary bladder or prostate. In fact, rhabdomyosarcoma is the most common bladder tumor in children under 10 years of age. Almost all pediatric tumors arising in this location are embryonal or botryoid rhabdomyosarcomas. , Those with a botryoid histology typically grow into the lumen of the urinary bladder as a grapelike, richly mucoid, multinodular or polypoid mass, with a broad base that can cause an obstruction of the internal urethral orifice and prostatic urethra. This, in turn, results in incontinence and difficulty with urination. Interestingly, however, adult rhabdomyosarcomas of the urinary bladder are more often of the alveolar type, which can cause morphologic confusion with small cell carcinoma. Rarely, rhabdomyosarcomas arise in other genitourinary or gynecologic sites, including the fallopian tube, uterus, cervix, vagina, labium and vulva, and perineum and perianal region. Tumors in these locations are often (but not always) of the botryoid subtype. Rhabdomyosarcomas that arise in gynecologic organs in adults are morphologically similar to those in pediatric patients, but they seem to behave more aggressively. , A significant subset of embryonal rhabdomyosarcomas occurring in the uterine cervix or corpus are of DICER1-mutant type.
Unlike adult soft tissue sarcomas, rhabdomyosarcomas involve the extremities much less often. Only 14.6% of cases from the Armed Forces Institute of Pathology (AFIP) series occurred in this location, with a similar incidence in the upper and lower extremities; alveolar rhabdomyosarcomas outnumbered embryonal rhabdomyosarcomas by 4:3, similar to IRS-I and IRS-II. Most pleomorphic rhabdomyosarcomas arise in the deep soft tissues of the extremities of adults.
Unusual rhabdomyosarcomas arise outside the aforementioned sites. Tumors originating in the hepatobiliary tract usually arise from the submucosa of the common bile duct; most are botryoid type with typical myxoid, grapelike gross and microscopic appearances.
Fusion-driven spindle cell rhabdomyosarcomas in adults segregate into two groups. The first and larger group usually occurs in bone (an otherwise very rare site for rhabdomyosarcomas) and most often harbors FUS/EWSR1::TFCP2 fusions. , A smaller group of these tumors occurs in various somatic soft tissue locations and displays significant diversity in fusion type.
Gross Findings
Rhabdomyosarcomas display few characteristic features grossly. As with other rapidly growing sarcomas, the appearance of the tumor reflects the degree of cellularity, relative amounts of collagenous or myxoid stroma, and presence and extent of secondary changes (e.g., hemorrhage, necrosis, ulceration). In general, tumors growing into body cavities, such as those in the nasopharynx and urinary bladder, are fairly well-circumscribed, multinodular, or distinctly polypoid. On cross-section, they show a glistening, gelatinous, gray–white surface, with patchy areas of hemorrhage or cyst formation. Deep-seated tumors involving or arising in the musculature are usually less well-defined and almost always infiltrate the surrounding tissues. They are firmer and rubbery, and have a mottled, gray–white to pink-tan, smooth or finely granular, often bulging surface. There are often areas of focal necrosis and cystic degeneration.
Histochemistry in the Diagnosis of Rhabdomyosarcomas
Although many rhabdomyosarcomas can be diagnosed with routine sections alone, a variety of poorly differentiated sarcomas masquerade as rhabdomyosarcomas (and vice versa). Therefore, ancillary diagnostic procedures are often essential for a reliable diagnosis. During the past 4 decades, conventional special stains, such as the periodic acid–Schiff (PAS) preparation or Masson trichrome stain, have been essentially replaced by immunohistochemical procedures. Rhabdomyosarcomas contain considerable amounts of intracellular, PAS-positive glycogen; in many tumors the glycogen is irregularly distributed and usually much more conspicuous in well-differentiated than poorly differentiated tumor cells.
Immunohistochemistry in the Diagnosis of Rhabdomyosarcomas
Chapter XX (Immunohistochemistry) covers in depth the various markers used in the diagnosis of rhabdomyosarcomas. Briefly, desmin is the best screening marker for potential rhabdomyosarcomas, in the evaluation of malignant neoplasms with round cell, spindle cell, pleomorphic or epithelioid features ( Fig. 20.1A–B ), although tumors composed predominantly of primitive cells may be only focally positive for this antigen. , As discussed in Chapter XX, desmin is by no means a specific marker of myogenic tumors, however, and in the modern era definitive diagnosis of rhabdomyosarcoma requires demonstration of more specific markers, in particular myogenin, MYOD1, and PAX7. Both myogenin and MYOD1 are highly specific markers of rhabdomyosarcoma ( Fig. 20.1C–D ). As is discussed below, there are some interesting differences in myogenin and MYOD1 expression in rhabdomyosarcoma subtypes, with, for example, diffuse expression of myogenin characterizing alveolar rhabdomyosarcoma and diffuse MYOD1 expression often pointing toward MYOD1-mutated spindle cell rhabdomyosarcoma. PAX7 is another highly sensitive marker of skeletal muscle differentiation, although it is not perfectly specific, being expressed in most Ewing sarcomas as well. In general, we use antibodies to actins only when the differential diagnosis includes leiomyosarcoma, keeping in mind that smooth muscle actin expression may be found in up to 13% of rhabdomyosarcomas. There is no role for myoglobin immunohistochemistry at this time, as this is a notably insensitive marker that is often challenging to interpret. ,
Diffuse, strong immunoreactivity for desmin in embryonal rhabdomyosarcoma ( A ) and in alveolar rhabdomyosarcoma ( B ). In contrast to embryonal rhabdomyosarcoma, which typically shows only patchy expression of myogenin ( C ), alveolar rhabdomyosarcomas are characterized by strong, uniform expression ( D ). This finding can be helpful in the distinction of the “dense” variant of embryonal rhabdomyosarcoma from alveolar rhabdomyosarcoma.
Recent expression profiling studies have established newer markers of rhabdomyosarcoma that are associated with histologic subtype and fusion status. Coexpression of AP-2β and P-cadherin is typically present in FOXO1 -rearranged alveolar rhabdomyosarcomas, whereas coexpression of epidermal growth factor receptor (EGFR) and fibrillin-2 is seen in most embryonal rhabdomyosarcomas. It has been suggested that an immunohistochemical panel consisting of myogenin, AP-2β, NOS-1, and HMGA2 may serve as immunohistochemical surrogates of fusion status in rhabdomyosarcoma, with fusion-positive alveolar rhabdomyosarcomas coexpressing myogenin, AP-2β, and NOS-1, without expression of HMGA2, and fusion-negative rhabdomyosarcomas having the opposite immunophenotype. Although not widely utilized in the United States, these panels may be of some value in settings where molecular genetic testing is not widely available.
General Aspects of Risk Stratification and Prognosis for Rhabdomyosarcoma
During the past 60 years, the prognosis of rhabdomyosarcoma has improved dramatically. Before 1960, the prognosis was extremely poor, and there were few survivors even after radical, often destructive and disfiguring, surgical therapy. For example, an AFIP study in 1969 reported a 5-year mortality rate of 98%.
Since the early 1960s, there has been marked improvement in the survival rates of patients with rhabdomyosarcoma, because of a multidisciplinary therapeutic approach that consists of a biopsy or surgical removal of the neoplasm and multiagent chemotherapy with or without radiotherapy. As a rule, treatment is carried out after a biopsy or resection and careful, comprehensive assessment of tumor stage or tumor group with radiography, computed tomography (CT) scans, magnetic resonance imaging, bone scans, and if necessary, angiograms. Positron emission tomography (PET) CT has emerged as a useful test for staging rhabdomyosarcoma, providing additional information on regional lymph nodes. Recommendations for therapy chiefly depend on the stage or clinical group of the disease, and the site of the tumor following accurate microscopic diagnosis.
The IRS-II study of patients younger than 21 years with a confirmed diagnosis of rhabdomyosarcoma distinguished four clinical groups based on the amount of tumor remaining after initial surgery ( Box 20.2 ). Because this approach is influenced by the variable practices of surgeons, the IRS Committee adopted a modification of the tumor–node–metastasis (TNM) system, which relies on a pretreatment assessment of tumor extent. This system includes evaluation of the site of the primary tumor, maximum diameter of the tumor, determination of tumor invasion into adjacent structures, status of regional lymph nodes, and presence or absence of distant metastases. More recent studies of rhabdomyosarcoma rely on both the IRS clinical grouping system and the TNM stage to determine therapy. Both the IRS clinical group and TNM stage have major prognostic significance ( Tables 20.2 and 20.3 ). Low-risk patients generally have localized embryonal histology tumors. Most of these patients have resected (group I or II) tumors, as well as group III tumors arising in favorable sites (e.g., the orbit). Patients with embryonal tumors that are group III, stage 2 or 3, and all patients with nonmetastatic alveolar tumors are intermediate risk . Patients with metastatic tumors (regardless of subtype) are treated with high-risk protocols. Based on IRS-IV data, overall survival rates were 95%, 75%, and 27% for low-risk, intermediate-risk, and high-risk patients, respectively. Similar results were reported from the European Cooperative Group studies, using a four-tier risk system. , As a direct result of advances in risk stratification and therapy secondary to the collaborative group clinical trials, the 5-year failure-free survival rate for low-risk patients is as high as 90%, the 4-year failure-free survival rate for intermediate-risk patients is almost 70%, but little progress has been made on improving survival for high-risk patients.
BOX 20.2
Clinical Staging of Patients with Rhabdomyosarcoma (IRS Classification)
From Maurer HM, Beltangady M, Gehan EA, et al. The Intergroup Rhabdomyosarcoma Study I: a final report. Cancer . 1988;61:209.
Group I
-
Localized disease, completely resected (regional nodes not involved)
-
Confined to muscle or organ of origin
-
Contiguous involvement with infiltration outside of the muscle or organ of origin, as through fascial planes
Group II
-
Grossly resected tumor with microscopic residual disease
-
No evidence of gross residual tumor; no evidence of regional node involvement
-
Regional disease, completely resected (regional nodes involved, extension of tumor into an adjacent organ, or both); all of tumor completely resected with no microscopic residual tumor
-
Regional disease with involved nodes, grossly resected, but with evidence of microscopic residual disease
Group III
-
Incomplete resection or biopsy with gross residual disease
Group IV
-
Distant metastatic disease present at onset (lung, liver, bones, bone marrow, brain, distant muscle, and nodes)
Table 20.2
TNM Pretreatment Staging Classification of Rhabdomyosarcoma
Modified from Dasgupta R, Fuchs J, Rodeberg D. Rhabdomyosarcoma. Semin Pediatr Surg . 2016;25:276–283.
| Stage | Sites | T a | Size b | N | M |
|---|---|---|---|---|---|
| 1 | Orbit, head and neck (including parameningeal), genitourinary (nonbladder/prostate), biliary tract/liver | T1 or T2 | a or b | N0, N1, or NX | M0 |
| 2 | Bladder/prostate, extremity, cranial, parameningeal, other (includes retroperitoneum, trunk) except biliary tract/liver | T1 or T2 | a | N0 or NX | M0 |
| 3 | Bladder/prostate, cranial, parameningeal, extremity, other (includes retroperitoneum, trunk) except biliary tract/liver | T1 or T2 |
a
b |
N1
N0 or N1 or NX |
M0
M0 |
| 4 | All | T1 or T2 | a or b | N0 or N1 | M1 |
Table 20.3
Risk Stratification of Patients with Rhabdomyosarcoma
Modified from Haduong JH, Heske CM, Allen-Rhoades W, et al. An update on rhabdomyosarcoma risk stratification and the rationale for current and future Children’s Oncology Group clinical trials. Pediatr Blood Cancer . 2022;69(4):e29511.
| Risk Group | Stage | Clinical Group | Age (years) | Fusion Status |
|---|---|---|---|---|
| Low | 1 | I, II, III (orbit only) | Any | FOXO1 -nonrearranged |
| 2 | I, II | Any | FOXO1 -nonrearranged | |
| Intermediate | 1 | III (non-orbit) | Any | FOXO1 -nonrearranged |
| 1, 2, 3 | I, II, III | Any | FOXO1 -rearranged | |
| 2, 3 | III | Any | FOXO1 -nonrearranged | |
| 3 | I, II | Any | FOXO1 -nonrearranged | |
| 4 | IV | ≤10 | FOXO1 -nonrearranged | |
| High | 4 | IV | ≥10 | FOXO1 -nonrearranged |
| 4 | IV | Any | FOXO1 -rearranged |
Age at diagnosis and anatomic site are also important predictors of outcome in patients with rhabdomyosarcoma. , Age has its greatest prognostic effect in patients with invasive but nonmetastatic tumors. With regards to site, tumors of the orbit have the best prognosis (92% 5-year survival), followed by tumors of the head and neck and non–bladder/prostate genitourinary tumors (about 80% 5-year survival). , A less favorable prognosis is found in patients whose tumors are located in a parameningeal location, bladder and prostate, and the extremities, with approximately 70% 5-year survival for each. The poorest prognosis occurs in patients with tumors at other sites, including the retroperitoneum, biliary tract, and peritoneum. Late detection and large tumor size, difficulties encountered during surgical removal, extension into the meninges (with or without spinal fluid spread), and lymph node metastasis are primarily responsible for the prognostic differences related to anatomic site.
As noted above, the natural histories of the different subtypes of rhabdomyosarcoma are considerably different, and these are best thought of as different tumor types sharing skeletal muscle differentiation, rather than simply morphologic variants of a single disease. Thus, while histologic classification of rhabdomyosarcomas has long been known to be of prognostic significance for patients with this disease, with for example botryoid embryonal rhabdomyosarcomas having an excellent prognosis, conventional embryonal rhabdomyosarcomas having an intermediate prognosis, and alveolar rhabdomyosarcomas having a poor prognosis, these older studies do not account for more recently described, genetically defined rhabdomyosarcoma subtypes, which may have an excellent prognosis (e.g., infantile spindle cell rhabdomyosarcomas with VGLL2 fusions) or an especially poor prognosis (e.g., MYOD1 -mutant rhabdomyosarcomas, EWSR1/FUS::TFCP2 -fused rhabdomyosarcomas). Therefore, molecular genetic subclassification is increasingly important for patients with these diseases.
Among molecular genetic parameters, gene fusion status unquestionably shows the strongest relationship with clinical behavior and patient outcome, as reflected in the current COG rhabdomyosarcoma risk stratification system ( Table 20.3 ). In this context, fusion status refers specifically to the presence or absence of rearrangement of the FOXO1 gene, as seen in alveolar rhabdomyosarcoma. This risk stratification system uses fusion status, rather than histologic subtype (i.e., alveolar vs. embryonal), in part to address difficulties in the distinction of the “dense” form of embryonal rhabdomyosarcoma from true alveolar rhabdomyosarcoma. Historically, it has been claimed that roughly 80% of alveolar rhabdomyosarcoma are FOX01 -rearranged, in contrast to less than 5% of embryonal rhabdomyosarcomas; these figures likely underestimate and overestimate the percentage of positive alveolar and embryonal tumors, respectively. Regardless, it is clear that fusion-negative tumors have a superior event-free survival than fusion-positive tumors. In the largest study to date, evaluating 1727 patients from IRS V and COG ARST studies, only the presence of metastatic disease surpassed FOXO1 fusion status as a predictor of poor outcome.
There are some data to suggest that PAX7::FOXO1 fusion is associated with a better prognosis than PAX3::FOXO1A fusion in patients with alveolar rhabdomyosarcoma. , A series of 171 rhabdomyosarcomas, published by Sorensen et al., identified PAX3::FOXO1 and PAX7::FOXO1 fusion transcripts in 55% and 22% of 78 patients with alveolar rhabdomyosarcomas; all embryonal rhabdomyosarcomas were fusion-negative. Although fusion status was not associated with outcome differences in patients with locoregional tumors, patients with metastatic disease whose tumors harbored PAX3::FOXO1 fusions had considerably worse 4-year survival, as compared to patients with PAX7::FOXO1 tumors. Two more recent studies, evaluating 287 patients with rhabdomyosarcoma, found significantly worse 5-year survival for patients with PAX3 fusion as compared to those with PAX7 fusions. , It has been suggested, however, that these findings may be confounded by the greater percentage of PAX3 -rearranged tumors occurring in older patients and in larger tumors.
It is important to appreciate that the above analyses apply only to “fusion-positive” tumors harboring canonical PAX3::FOXO1 and PAX7::FOXO1 fusions and not to alveolar rhabdomyosarcomas with extremely rare variant fusions, such as PAX3::FOXO4 , PAX3::NCOA1 , PAX3::INO80D , or FOXO1::FGFR1 ; the clinical significance of these molecular genetic events is unknown. Similarly, infantile spindle cell rhabdomyosarcomas harboring rearrangements of the VGLL2 , TEAD1 , and NCOA2 loci generally have an excellent prognosis and should not be included among the “fusion-positive” tumors for risk assessment purposes. , Conversely, the prognosis for some “ FOXO1 -negative” rhabdomyosarcomas is quite poor, in particular MYOD1 -mutant spindle cell/sclerosing rhabdomyosarcomas in children and adults, , and adult spindle cell rhabdomyosarcomas harboring EWSR1/FUS::TFCP2 .
A variety of other molecular genetic alterations may also have prognostic significance in patients with rhabdomyosarcoma. For example, amplifications of 2p24 ( MYCN ) and 12q13-q14 ( CDK4 ), found in 10%–15% of alveolar rhabdomyosarcomas, have been associated with worse outcome, although data are limited. , TP53 mutations are also associated with poor prognosis in alveolar rhabdomyosarcomas, although they are present in only a very small minority of cases (∼4%), and in embryonal rhabdomyosarcomas.
General Aspects of the Differential Diagnosis of Rhabdomyosarcomas
Poorly differentiated round and spindle cell sarcomas, especially in children or young adults, constitute the most common problem in differential diagnosis. Included in this group are neuroblastoma, Ewing sarcoma, poorly differentiated angiosarcoma, synovial sarcoma, malignant melanoma, melanotic neuroectodermal tumor of infancy, granulocytic sarcoma, and lymphoma. Small cell carcinoma must also be considered when the tumor occurs in a patient older than 45 years. The differential diagnosis requires not only careful evaluation of clinical data, patient age, and tumor location, but also a painstaking examination of multiple sections for specific features (e.g., rhabdomyoblasts, rosettes, biphasic cellular or vascular differentiation, and intracellular pigment). Immunohistochemical assessment with multiple markers and often molecular genetic testing are important ancillary tools (as described earlier). Immunohistochemical analysis using a battery of antibodies is indispensable, including stains for muscle markers such as desmin, muscle-specific actin, and MyoD1 or myogenin. It must also be kept in mind that CD99, although a highly sensitive marker of Ewing sarcoma, is sometimes detected in embryonal or alveolar rhabdomyosarcoma.
Problems in diagnosis may also be caused by benign reactive and neoplastic lesions. They include polypoid cystitis, polyps and pseudosarcomatous myofibroblastic proliferations of the genitourinary tract, infectious granuloma, proliferative myositis, skeletal muscle regeneration, granular cell tumor, and fetal rhabdomyoma. Desmin and more limited expression of myogenin/MYOD1 may be seen in fibroepithelial polyps of the female genital tract, a potentially serious pitfall. Conversely, sparsely cellular, botryoid rhabdomyosarcomas (initially misinterpreted as “myxomas”) may occur. In these cases, consideration of age and location usually allows for the correct diagnosis, because myxomas are virtually nonexistent in children and almost never occur in visceral organs.
Some tumors have heterologous rhabdomyoblastic components . Focal rhabdomyoblastic differentiation occurs in a variety of malignant neoplasms, including those with sarcomatous differentiation only, those with epithelial or germ cell elements, and tumors of neuroectodermal derivation ( Box 20.3 ). Identification of such elements may be obvious by light microscopy alone, but in some cases, immunohistochemistry (IHC) is required to support rhabdomyoblastic differentiation. In addition, sarcomas with a propensity for undergoing dedifferentiation, including chondrosarcomas and liposarcomas, may have areas of divergent rhabdomyoblastic differentiation. Mesenchymal chondrosarcoma typically shows rhabdomyoblastic differentiation in the form of desmin, MyoD1, and myogenin expression, although rhabdomyoblasts are not seen. Similarly, recently described EWSR1::PATZ1 sarcomas commonly express desmin, myogenin and MYOD1 and may even contain rhabdomyoblasts; these rare sarcomas are not currently considered to represent rhabdomyosarcomas for purposes of clinical management.
BOX 20.3
Tumors with Heterologous Rhabdomyoblastic Components
Modified from Woodruff JM, Perino G. Non-germ-cell or teratomatous malignant tumors showing additional rhabdomyoblastic differentiation, with emphasis on the malignant Triton tumor. Semin Diagn Pathol . 1994;11:69.
Tumors with Epithelial Components
-
Carcinosarcoma (especially of breast, stomach, urinary bladder)
-
Malignant mixed Müllerian tumor (uterus, cervix, ovary)
-
Wilms tumor
-
Hepatoblastoma
-
Pulmonary blastoma
-
Thymoma
Tumors with Germ Cell or Sex Cord Elements
-
Germ cell tumors (seminoma, teratoma)
-
Sertoli–Leydig cell tumor
Tumors with Sarcomatous Elements Only
-
Dedifferentiated chondrosarcoma
-
Dedifferentiated liposarcoma
Tumors of Neuroectodermal Derivation
-
Malignant peripheral nerve sheath tumor (malignant Triton tumor)
-
Ectomesenchymoma
-
Medulloepithelioma
-
Medulloblastoma
-
Congenital pigmented nevus (giant nevus)
Epithelial tumors may also exhibit rhabdomyoblastic differentiation, including malignant mixed mesodermal tumors of the uterus, cervix, or ovary; carcinosarcomas of the breast and stomach; pulmonary blastomas; nephroblastomas; and mixed-type hepatoblastomas. The rhabdomyoblastic component may even dominate the microscopic picture. Rhabdomyoblastic differentiation is also encountered in malignant or immature teratomas, but rarely as a major element. In most of these tumors, the rhabdomyoblastic component is accompanied by malignant epithelial and other mesenchymal elements, such as cartilage and bone. Rare ovarian Sertoli–Leydig cell tumors contain heterologous rhabdomyoblastic foci.
Rhabdomyoblastic elements also may be found in various neuroectodermal neoplasms, including malignant peripheral nerve sheath tumor (so-called malignant Triton tumor), ganglioneuroma (ectomesenchymoma), medulloepithelioma, and medulloblastoma. Malignant peripheral nerve sheath tumors with rhabdomyoblastic differentiation chiefly occur in patients older than 30 who have manifestations of type 1 neurofibromatosis. Malignant ectomesenchymoma is primarily a tumor of infants and young children and is not known to be associated with neurofibromatosis; it consists of a mixture of rhabdomyoblastic elements, mature ganglion cells, and neuroma-like structures. Huang et al. found consistent HRAS mutations, and a gene signature that suggested a close relationship to embryonal rhabdomyosarcoma.
Rhabdomyosarcoma Subtypes
Embryonal Rhabdomyosarcoma
Embryonal rhabdomyosarcoma-not otherwise specified accounts for approximately 60% of all rhabdomyosarcomas, occurring in 2.6 per million children younger than 15 years in the United States. It mostly affects children younger than 10 (mean age: almost 7 years), but it also occurs in adolescents and young adults. In contrast, it is uncommon in patients older than 40. There is a slight male predominance. The most common site of involvement is the head and neck, particularly the orbit and parameninges ( Table 20.3 ). After the head and neck, this tumor is most commonly found in the genitourinary tract, followed by the deep soft tissues of the extremities and the pelvis and retroperitoneum.
Histologically, embryonal rhabdomyosarcoma closely resembles various stages in the embryogenesis of normal skeletal muscle. However, its pattern is much more variable, ranging from poorly differentiated tumors that are difficult to diagnose without immunohistochemical examination, to well-differentiated neoplasms that resemble fetal muscle. Features common to most include (1) varying degrees of cellularity, alternating between densely packed, hypercellular areas and loosely textured, myxoid areas ( Figs. 20.2–20.5 ); (2) a mixture of poorly oriented, small, undifferentiated, hyperchromatic, round or spindle-shaped cells, along with a varying number of differentiated cells with eosinophilic cytoplasm, characteristic of rhabdomyoblasts ( Figs. 20.6–20.8 ); and (3) a matrix containing little collagen and varying amounts of myxoid material. Cross-striations are discernible in 50%–60% of cases.
Low-power view of embryonal rhabdomyosarcoma with alternating cellular and myxoid areas, a characteristic feature of this tumor.
Alternating cellular and myxoid zones in embryonal rhabdomyosarcoma.
High-power view of embryonal rhabdomyosarcoma composed predominantly of primitive ovoid cells.
Primitive spindle-shaped cells deposited in abundant myxoid stroma in embryonal rhabdomyosarcoma.
( A ) Embryonal rhabdomyosarcoma composed principally of primitive round cells. ( B ) High-power view showing more mature rhabdomyoblasts.
Embryonal rhabdomyosarcoma composed of cells, both rounded and spindled, that are larger than those in Fig. 20.6 .
( A ) Embryonal rhabdomyosarcoma composed of larger cells than in Fig. 20.6 . Note that the cells vary from spindled ( B ) to rounded ( C ).
The least well-differentiated examples of embryonal rhabdomyosarcoma correspond in appearance to developing muscle at 5–8 weeks’ gestation. For the most part, they consist of small, round or spindle-shaped cells with darkly staining hyperchromatic nuclei and indistinct cytoplasm. The nuclei vary slightly in size and shape (more so than those of alveolar rhabdomyosarcoma), have one or two small nucleoli, and usually exhibit a high rate of mitotic activity. Differentiated rhabdomyoblasts are either absent entirely or are confined to a few small areas, making it mandatory to examine multiple sections from different portions of the tumor; adjunctive diagnostic procedures are required to confirm the diagnosis in virtually all cases (discussed later). This has been referred to as the “dense” form of embryonal rhabdomyosarcoma, and may closely simulate alveolar rhabdomyosarcoma.
Better-differentiated examples have, in addition to the primitive or undifferentiated cellular areas, larger round or oval eosinophilic cells, characteristic of rhabdomyoblasts ( Figs. 20.7–20.9 ). The cytoplasm of these cells contains granular material or deeply eosinophilic masses of stringy or fibrillary material, concentrically arranged near or around the nucleus. Cross-striations are rare in the round cells; if present, they are usually confined to narrow bundles of concentrically arranged myofibrils at the circumference of the rhabdomyoblast ( Fig. 20.9 ). Degenerated rhabdomyoblasts with a glassy or hyalinized, deeply eosinophilic cytoplasm and pyknotic nuclei, but without cross-striations, are a frequent feature of this tumor.
Characteristic rhabdomyoblasts in embryonal rhabdomyosarcoma. Deeply eosinophilic fibrillar material is concentrically arranged around the nucleus.
Cross-striations are more readily discernible in embryonal rhabdomyosarcomas with a more prominent spindle cell component, tumors that might be regarded as the morphologic equivalent of normal muscle at 9–15 weeks of intrauterine development ( Figs. 20.10 and 20.11 ). These neoplasms are composed mainly of a mixture of undifferentiated cells and differentiated fusiform or elongated cells that are readily identifiable as rhabdomyoblasts on light microscopy. The rhabdomyoblasts range from slender spindle-shaped cells with a small number of peripherally placed myofibrils, to large eosinophilic cells with a strap, ribbon, tadpole, or racket shape, one or two centrally positioned nuclei, and prominent nucleoli, with or without cross-striations. Cross-striations in neoplastic cells differ from those in residual or entrapped muscle cells by their more irregular distribution and because they often traverse only part of the tumor cell. Intracellular granules may be confused with cross-striations, but their granular nature is readily apparent after a careful examination of the cell under oil immersion. Sometimes, the strap-shaped cells are sharply angulated, and form a diagnostically useful zigzag or “broken straw” pattern. Most of these tumors have only a moderate degree of cellular pleomorphism.
Embryonal rhabdomyosarcoma composed predominantly of atypical spindle-shaped cells with scattered elongated rhabdomyoblasts.
High-power view of elongated rhabdomyoblasts with distinct cross-striations in embryonal rhabdomyosarcoma.
Defined similarly in Wilms tumor, anaplasia in embryonal rhabdomyosarcoma consists of large, lobate, hyperchromatic nuclei (at least three times the size of neighboring nuclei), with or without large, atypical mitotic figures. Embryonal rhabdomyosarcomas with anaplasia are rare. While some cases are difficult to distinguish from adult pleomorphic rhabdomyosarcomas ( Fig. 20.12 ), the more common cross-striations in childhood tumors and the identification of areas of more typical embryonal rhabdomyosarcoma facilitate the diagnosis. The clinical significance of anaplasia is controversial; some studies have found survival in patients with embryonal rhabdomyosarcomas showing diffuse anaplasia to be similar to that of patients with alveolar rhabdomyosarcoma, , whereas more recent multivariate analyses have not found anaplasia to be of prognostic significance, although it is more common in TP53 -mutated tumors.
Embryonal rhabdomyosarcoma with anaplastic features arising in a 3-year-old child.
There are also extremely well-differentiated embryonal rhabdomyosarcomas, whose features include almost entirely rounded, spindle-shaped, or polygonal rhabdomyoblasts with abundant eosinophilic cytoplasm and frequent cross-striations. Some of these differentiated tumors are found in recurrent or metastatic neoplasms after prolonged therapy ( Fig. 20.13 ), possibly because of the selective destruction of undifferentiated tumor cells. ,
Embryonal rhabdomyosarcoma consisting almost entirely of differentiated rhabdomyoblasts, a feature occasionally encountered in recurrent tumors after therapy.
Glycogen is demonstrable in most rhabdomyosarcomas, regardless of type. Removal of the glycogen during fixation results in multivacuolated cells or spider cells, which are large rhabdomyoblasts with narrow strands of cytoplasm connecting the center of the cell with its periphery. The centrally located nuclei and the irregular shape of the cytoplasmic vacuoles help distinguish these cells from the more rounded, lipid-filled vacuoles of lipoblasts. In contrast to alveolar rhabdomyosarcoma, multinucleated giant cells are rare in embryonal rhabdomyosarcomas.
Occasionally, embryonal rhabdomyosarcoma displays, in addition to its rhabdomyoblastic component, foci of immature cartilaginous ( Fig. 20.14 ) or osseous components, or both. These tumors are particularly common in the uterine cervix and corpus, the fallopian tube and ovary, and the vagina, are frequently DICER1 -altered, and show overlapping morphologic, genetic, and epigenetic features with other DICER1 -altered neoplasms. We have seen identical tumors in the male genitourinary tract.
Embryonal rhabdomyosarcoma with foci of immature cartilage.
Botryoid embryonal rhabdomyosarcoma accounts for approximately 6% of all rhabdomyosarcomas. The botryoid variant (Greek botrys , “bunch of grapes”) is characterized grossly by its polypoid (grapelike) growth. Microscopically, it demonstrates a relative sparsity of cells and abundance of mucoid stroma, often resulting in a myxoma-like picture. Most botryoid rhabdomyosarcomas are found in mucosa-lined, hollow organs, such as the nasal cavity, nasopharynx, bile duct, urinary bladder, and vagina ( Fig. 20.15 ). Tumors of this type may also be encountered in areas where the expanding neoplasm reaches the body surface, as in some rhabdomyosarcomas of the eyelid or anal region. Clearly, its unrestricted growth in body cavities or on body surfaces accounts for its characteristic edematous and botryoid appearance.
Botryoid rhabdomyosarcoma arising in vagina of child.
Although a grapelike configuration has traditionally been a defining feature of the botryoid variant, the ICR scheme does not require this characteristic gross appearance. According to the ICR criteria, a cambium layer , characterized by a subepithelial condensation of tumor cells separated from an intact surface epithelium by a zone of loose stroma, must be present to recognize this variant ( Figs. 20.16–20.20 ). The tumor cells should form a distinct zone that is several layers thick, although the thickness may vary in extent in different areas of the tumor. The cells range from primitive small cells to cells with clear-cut rhabdomyoblastic differentiation ( Fig. 20.20 ). Cells with stellate cytoplasmic processes are often prominent. The stroma is typically loosely cellular with a myxoid appearance, including a hypocellular zone that separates the surface epithelium from the underlying cambium layer. The surface epithelium may be hyperplastic or may undergo squamous changes, sometimes mimicking a carcinoma.
Polypoid submucosal growth of botryoid rhabdomyosarcoma.
Botryoid rhabdomyosarcoma showing typical submucosal location.
Botryoid rhabdomyosarcoma of biliary tract.
Botryoid rhabdomyosarcoma showing the characteristic “cambium” layer of cells. Submucosal in location, the cells are condensed beneath a zone of loose stroma.
Botryoid rhabdomyosarcoma showing combination of spindled ( A ) and rounded ( B ) cellular areas.
By immunohistochemistry, embryonal rhabdomyosarcomas are typically strongly positive for desmin and more variably positive for myogenin and MYOD1. Smooth muscle actin expression may also be seen.
The molecular underpinnings of embryonal rhabdomyosarcoma are complex and characterized by various chromosomal gains and losses. Whole chromosome gains (chromosomes 2, 8, 11, 12, 13, and 20) are relatively common, , but some show whole chromosome losses, including monosomy 10 and 15. The most characteristic finding is loss of heterozygosity (LOH) for multiple, closely linked loci at chromosome 11p15.5. , This molecular alteration results in inactivation of growth factors and tumor suppressor genes, including GOK , H19 , CDKN1C , HOTS , and IGF2 . In a comprehensive analysis of rhabdomyosarcoma by comparative genomic hybridization (CGH), Shern et al. found a higher number of oncogenic mutations in embryonal rhabdomyosarcoma than in the alveolar subtype, including alterations in NRAS , KRAS , HRAS , FGFR4 , PIK3CA , CTNNB1 , FBXW7 , and BCOR . The majority of these tumors show alterations of the receptor tyrosine kinase/ RAS/PIK3CA axis, providing potential opportunities for therapeutic intervention. Aberrations of the ALK gene are also frequently seen in embryonal rhabdomyosarcomas and have been associated with metastatic disease and poor disease-specific survival. , They also offer an opportunity for targeted therapy with ALK inhibitors. Genes involved in the hedgehog pathway, including GLI1 and PTCH1 , have also been implicated in the pathogenesis of this tumor. , , TP53 mutations are present in roughly 10% of embryonal rhabdomyosarcomas, and are associated with more aggressive behavior and adverse patient outcome. ,
Alveolar Rhabdomyosarcoma
Alveolar rhabdomyosarcoma is the second most common subtype, accounting for approximately 31% of all rhabdomyosarcomas. This variant tends to arise at a slightly older age than embryonal rhabdomyosarcoma, with a peak incidence at 10–25 years. It has a predilection for the deep soft tissues of the extremities, although the tumor may arise in many other sites, including the head and neck, , genitourinary tract, and gynecologic sites.
Histologically, alveolar rhabdomyosarcoma is mainly composed of ill-defined aggregates of poorly differentiated round or oval tumor cells that frequently show central loss of cellular cohesion and formation of irregular alveolar spaces ( Figs. 20.21–20.28 ). The individual cellular aggregates are separated and surrounded by a framework of dense, frequently hyalinized fibrous septa that surround dilated vascular channels. Characteristically, the cells at the periphery of the alveolar spaces are well preserved and adhere in a single layer to the fibrous septa in a manner somewhat reminiscent of an adenocarcinoma or papillary carcinoma. The cells in the center of the alveolar spaces tend to be more loosely arranged, or freely floating ( Figs. 20.25 and 20.26 ); they are often poorly preserved and show evidence of degeneration and necrosis. In rare instances, viable cells are virtually absent, and the tumor consists merely of a coarse, sievelike or honeycomb-like meshwork of thick, fibrous trabeculae. The trabeculae surround small, loosely textured groups of severely degenerated cells with pyknotic nuclei and necrotic cellular debris.
Alveolar rhabdomyosarcoma with characteristic alveolar growth pattern.
Solid Pattern in Alveolar Rhabdomyosarcoma.
( A ) Centrally located cells in nests have not yet lost cellular cohesion to form an alveolar pattern. However, note the fibrous bands between the nests, which provide a clue to the diagnosis. ( B ) High-power view of cells showing relative uniformity compared to embryonal rhabdomyosarcoma.
Alveolar rhabdomyosarcoma showing more cellular variation than in Fig. 20.22 and incipient alveolar pattern.
Bizarre giant cells in alveolar rhabdomyosarcoma.
( A ) Alveolar rhabdomyosarcoma in which alveolar pattern is evident but not as well defined as in Fig. 20.21 . ( B ) Numerous differentiating rhabdomyoblasts are evident within the tumor.
Medium-power ( A ) and high-power ( B ) views of alveolar rhabdomyosarcoma, featuring rare, bizarre giant cells.
Cells in alveolar rhabdomyosarcoma illustrating greater degree of uniformity than those of embryonal rhabdomyosarcoma.
Metastatic alveolar rhabdomyosarcoma to a lymph node. The alveolar pattern is present in the metastasis as well.
Solid forms of this tumor may lack an alveolar pattern entirely. Instead, they are composed of densely packed groups or masses of tumor cells that resemble the round cell areas of embryonal rhabdomyosarcoma, but demonstrate a more uniform cellular picture ( Figs. 20.22 and 20.25 ). These solidly cellular areas are more often encountered at the periphery of the tumor, and probably represent the most active and most cellular stage of growth. In most cases, examination of the solid tumor shows, in addition to the uniform cellular pattern, incipient alveolar features. Even in the solid areas, there is a regular arrangement of fibrous septa that surround the primitive round cells. Also, in rare cases the cells have abundant pale-staining, glycogen-containing cytoplasm and vaguely resemble clear cell carcinoma or clear cell malignant melanoma (clear cell rhabdomyosarcoma). ,
The individual cells in both alveolar and solid portions of the tumor have round or oval hyperchromatic nuclei with scant amounts of indistinct cytoplasm. Bulbous or club-shaped cells, sometimes with deeply eosinophilic cytoplasm, are often seen protruding from the fibrous walls into the lumen of the alveolar spaces. Mitotic figures are common. Neoplastic rhabdomyoblasts that display pronounced stringy or granular eosinophilic cytoplasm are less common in alveolar than in embryonal rhabdomyosarcomas, but are still present in up to 30% of cases. Most of the rhabdomyoblasts in the alveolar spaces have a round or oval configuration ( Fig. 20.27 ); those located in or attached to the fibrous septa tend to be strap or spindle shaped. If present, cross-striations are almost exclusively found in the spindle-shaped cells.
Multinucleated giant cells are a prominent and diagnostically important feature ( Figs. 20.24 and 20.26 ). Usually, the giant cells have multiple, peripherally placed nuclei, as well as pale-staining or weakly eosinophilic cytoplasm, without cross-striations. Transitional forms between rhabdomyoblasts and giant cells suggest that the latter are formed by cellular fusion. Collagen formation is usually confined to the intervening septa, but occasionally, large portions of the tumor are obliterated by extensive fibroplasia.
Very rare tumors have been described as showing mixed features of alveolar and embryonal rhabdomyosarcoma. However, most of these tumors lack PAX3/77::FOXO1 fusions and seem to be more closely related both clinically and biologically to embryonal rhabdomyosarcoma.
Metastatic alveolar rhabdomyosarcomas in lymph nodes, lung, and other viscera also display a distinct alveolar pattern ( Fig. 20.28 ), making it unlikely that this pattern is merely the result of infiltrative growth along the fibrous framework of the involved musculature. Diffuse bone marrow metastases may be mistaken for leukemia. ,
Immunohistochemically, alveolar rhabdomyosarcomas are usually (but not always) strongly positive for desmin, and diffusely positive for myogenin. Lesser degrees of MYOD1 expression are usually seen. Expression of keratins and neuroendocrine markers (e.g., synaptophysin, CD56) is common in alveolar rhabdomyosarcomas and may represent a significant diagnostic pitfall, particularly when the differential diagnosis includes small cell carcinoma (e.g., in older adults or in mucosal/visceral locations). PAX7 is typically diffusely positive. ALK gene copy number gain and expression of ALK protein have been reported in the majority of alveolar rhabdomyosarcomas. ,
Alveolar rhabdomyosarcoma is characterized by distinctive cytogenetic abnormalities that allow its distinction from other rhabdomyosarcoma subtypes and other round cell neoplasms in the differential diagnosis. Somewhere between 80% and 90% of alveolar rhabdomyosarcomas harbor fusions between either the PAX3 gene, located on chromosome 2q36.1, or the PAX7 gene, located on chromosome 1p36.13 with the FOXO1 (formerly FKHR ) gene, located on 13q14.11. , The PAX3::FOXO1 fusion is more common, accounting for 60%–70% of cases, whereas 10%–20% contain PAX7::FOXO1 fusions ( Table 20.4 ). , Both PAX3 and PAX7 encode transcription factors that regulate the expression of specific target genes; the encoded chimeric protein activates expression of genes with PAX3 -binding sites, including MCYN .
Table 20.4
Distribution of Anatomic Sites of Rhabdomyosarcoma Subtypes for 1626 IRS-I and IRS-II Patients
Modified from Newton Jr WA, Soule EH, Hamoudi AB, et al. Histopathology of childhood sarcomas, Intergroup Rhabdomyosarcoma Studies I and II: clinicopathologic correlation. J Clin Oncol . 1988;6:67.
| Site | Embryonal | Alveolar | Botryoid | Pleomorphic | Other | Total No. |
|---|---|---|---|---|---|---|
| Head and neck | 411 (71%) | 76 (13%) | 13 (2%) | 77 (13%) | 577 | |
| Genitourinary | 246 (71%) | 8 (2%) | 70 (20%) | 1 (<1%) | 23 (7%) | 348 |
| Extremities | 76 (24%) | 156 (50%) | 5 (2%) | 74 (24%) | 311 | |
| Trunk | 27 (19%) | 43 (30%) | 3 (2%) | 71 (49%) | 144 | |
| Pelvis | 45 (48%) | 19 (20%) | 29 (31%) | 93 | ||
| Retroperitoneum | 44 (59%) | 14 (19%) | 1 (1%) | 16 (21%) | 75 | |
| Perineum/anus | 13 (33%) | 19 (48%) | 1 (2%) | 1 (2%) | 6 (15%) | 40 |
| Other sites | 15 (39%) | 9 (24%) | 4 (11%) | 10 (26%) | 38 |
Although 10%–20% of alveolar rhabdomyosarcomas have historically been thought to be fusion-negative, this percentage is dropping. A very small percentage of alveolar rhabdomyosarcomas harbor variant fusions, including PAX3::FOXO4 , PAX3::NCOA1 , PAX3::INO80D , or FOXO1::FGFR1 . Other “fusion-negative alveolar rhabdomyosarcomas” likely represent the so-called “dense” variant of embryonal rhabdomyosarcoma or MYOD1 -mutant sclerosing rhabdomyosarcomas with a prominent microalveolar pattern. Other molecular genetic events that have been reported in small subsets of alveolar rhabdomyosarcomas include amplifications of 2p24 ( MYCN ) and 12q13-q14 ( CDK4 ), TP53 mutations, CDKN2A/CDKN2B mutations, and activating mutations of FGFR4 . , ,
Pleomorphic Rhabdomyosarcoma
Pleomorphic rhabdomyosarcoma is a rare variant of rhabdomyosarcoma that almost always arises in adults older than 45. Given its extreme rarity in children, this subtype was not included in the ICR. The concept of pleomorphic rhabdomyosarcoma has changed considerably since its inclusion in the 1958 Horn and Enterline classification. One-third of the 39 tumors in their study were designated as pleomorphic rhabdomyosarcomas, most of which arose in the deep soft tissues of the extremities of adults. Studies in the 1960s described the clinicopathologic features of pleomorphic rhabdomyosarcoma, which accounted for 9%–14% of all soft tissue sarcomas. However, with the emergence of the concept of malignant fibrous histiocytoma , many pleomorphic rhabdomyosarcomas were subsequently reclassified as storiform-pleomorphic variants of malignant fibrous histiocytoma, and thus pleomorphic rhabdomyosarcoma became regarded as rare or nonexistent. , Subsequently, with IHC and refined recognition of tumors with skeletal muscle differentiation, studies confirmed the existence of pleomorphic rhabdomyosarcoma and delineated criteria by which this sarcoma could be distinguished from other pleomorphic sarcomas. ,
Peak incidence occurs in the sixth decade, with a predilection for males. The tumor usually arises in the skeletal muscle of the extremities, particularly the thigh. Less often, these tumors arise in the abdomen/retroperitoneum, chest/abdominal wall, spermatic cord/testes, and upper extremities. , Rare examples have been reported in the head and neck, gynecologic region, and genitourinary tract. Most present with a rapidly growing, painless mass of several months’ duration.
Pleomorphic rhabdomyosarcomas are usually large (>10 cm), fleshy, well-circumscribed, intramuscular masses, with focal hemorrhage and extensive necrosis. Histologically, pleomorphic rhabdomyosarcoma is distinguished by its loosely arranged, haphazardly oriented, large, round or pleomorphic cells with hyperchromatic nuclei and deeply eosinophilic cytoplasm ( Figs. 20.29–20.32 ). As in embryonal rhabdomyosarcomas, there are racket-shaped and tadpole-shaped rhabdomyoblasts, but they are generally larger with more irregular outlines. Cells with cross-striations are typically found in embryonal rhabdomyosarcomas with focal pleomorphic or anaplastic features, but are rare in adult pleomorphic rhabdomyosarcomas. The tumor cells may be arranged in a haphazard pattern, but arrangement in a storiform pattern or a fascicular pattern (reminiscent of leiomyosarcoma) may be present ( Fig. 20.30 ). The most helpful feature suggesting this diagnosis by light microscopy is the presence of large, bizarre tumor cells with deeply eosinophilic cytoplasm and some cell-to-cell molding ( Fig. 20.29 ). Rare lesions have cells with a rhabdoid morphology characterized by a peripherally located vesicular nucleus, prominent nucleolus, and intracytoplasmic eosinophilic hyaline inclusion. Other features include phagocytosis by tumor cells, intracytoplasmic glycogen, and a moderately dense lymphohistiocytic infiltrate. When primitive round cell areas are present, the diagnosis of pleomorphic rhabdomyosarcoma should be questioned, and the diagnosis of the alveolar variant considered.
Pleomorphic rhabdomyosarcoma showing admixture of spindled and rounded rhabdomyoblasts.
Pleomorphic rhabdomyosarcoma with a fascicular architecture, featuring predominantly spindle-shaped cells.
