Nonneoplastic Lesions of the Larynx



Nonneoplastic Lesions of the Larynx





The larynx is most often biopsied because of suspicion of malignancy. Many biopsies will be diagnosed as conventional squamous cell carcinomas; however, nonneoplastic pathologies can also involve the larynx (Table 15.1). This chapter reviews the various infectious and inflammatory processes that can involve the larynx, as well as nonneoplastic polyps and cysts.


CONTACT ULCER

Contact ulcer or “laryngeal granuloma” is a relatively common lesion that typically involves the posterior portion of one or both sides of the larynx. The descriptor “contact” emphasizes the traumatic etiology for most of the lesions which includes, but is not limited to, endotracheal intubation, acid reflux (peptic contact ulcer), and vocal cord abuse related to shouting, coughing, etc.1,2,3,4,5,6 Patients tend to be older than 30 years and most are men. Most patients present with hoarseness and may be noted to have low-pitched voices and frequent coughing. Occasional patients may present with severe pain. The posterior vocal cords are usually ulcerated; however, some lesions can have a marked nodular or polypoid appearance simulating neoplasia.2,5,6 Although the epithelium is frequently ulcerated and covered with a fibrinous exudate (Fig. 15.1, eFig. 15.1), lesions can be covered by a proliferative epithelium or even pseudoepitheliomatous hyperplasia. Abundant granulation tissue is seen either at the ulcer site or immediately beneath the squamous epithelium and comprises the bulk of the lesion (Fig. 15.2, eFig. 15.2). Occasional atypical stromal cells may be seen; however, stromal mitotic figures are rare (eFig. 15.3).6 The granulation tissue is composed of numerous capillaries and a mixed inflammatory infiltrate. It should not have the lobular growth pattern typical of lobular capillary hemangiomas that are found in the mouth and sinonasal area. Indeed, true lobular capillary hemangiomas or pyogenic granulomas of the larynx either do not occur or are extremely rare.7









TABLE 15.1 Nonneoplastic Disease of the Larynx




























Traumatic



Contact ulcer


Vocal cord polyps


Infectious



Fungal


Mycobacterial


Bacterial


Autoimmune



Rheumatoid arthritis


Systemic lupus erythematosis


Relapsing polychondritis


Sjogren syndrome


Wegener granulomatosis


Crohn disease


Vesiculobullous disease


Deposition



Gout


Amyloid


Other



Cysts (laryngocele, saccular cysts, and ductal cysts)


Foreign body reactions (e.g., Teflon)


Sarcoid


Eosinophilic angiocentric fibrosis


Involvement by tracheopathia osteoplastica


Hamartoma



FOREIGN BODY REACTION

Foreign body reactions within the larynx are most often iatrogenic.5,8,9,10,11 The most extensively studied reaction is that secondary to Teflon injection.5,8,11 Teflon or polytetrafluoroethylene is a synthetic substance that can be injected into a paralyzed vocal cord to restore glottic competence. In general, this induces a localized foreign body giant cell reaction that is walled off by fibrous tissue. Occasionally, the material may infiltrate into surrounding tissues. The resultant foreign body reaction may form a mass that bulges into the larynx. Histologically, clusters and
sheets of multinucleated foreign body-type giant cells that contain birefringent clear material are present with intermixed chronic inflammation and fibrosis (Fig. 15.3, eFigs. 15.4 and 15.5). Other material, including silicone, Gore-Tex, and titanium, may be used for vocal cord
medialization.9,10 These foreign materials are generally not absorbed and induce surrounding fibrosis and chronic inflammation with a variable foreign body reaction.






FIGURE 15.1 A contact ulcer with eroded epithelium and a fibrinous exudate.






FIGURE 15.2 Abundant chronic inflammation can be seen within the stroma of a contact ulcer.






FIGURE 15.3 Foreign body giant cells with foreign material are observed in this reaction to Teflon.


INFECTIOUS DISEASE

The larynx may be infected by a great host of organisms that more commonly involve the lungs or sinonasal area. Many of these entities present as mass lesions and an infectious etiology is often unsuspected. Pathologists, however, should be well aware of these lesions as the correct diagnosis can spare a patient unnecessary treatment.


Tuberculosis

Patients with long-standing tuberculosis frequently are noted to have laryngeal involvement in advanced disease.12 Since the advent of effective antituberculosis treatments, laryngeal involvement has only seldom been reported, and when reported, it has been described as a mimic of laryngeal carcinoma.12,13,14,15,16 As such, patients are older, usually in their fifth or sixth decades of life, and typically present with hoarseness and a solitary laryngeal mass that frequently involves the vocal cords. Only rarely do patients have more developed pulmonary symptoms (although pulmonary disease may be present). Grossly, the lesions are sometimes ulcerated and can appear granular and nodular. Laryngeal disease shares the
histologic features of tuberculosis found elsewhere with caseating granulomatous inflammation and Langhans giant cells (Fig. 15.4, eFig. 15.6).15 Histochemical and immunohistochemical staining for acid-fast bacilli can sometimes be helpful given the differential that must be considered (Table 15.2).






FIGURE 15.4 Laryngeal tuberculosis appears similar to tuberculosis seen at other sites in the body with necrotizing granulomatous inflammation.








TABLE 15.2 Granulomatous Disease of the Larynx





Tuberculosis


Leprosy


Histoplasmosis


Blastomycosis


Coccidiomycosis


Candidiasis


Rhinoscleroma


Sarcoidosis


Wegener granulomatosis


Foreign body reaction (e.g., Teflon)


Amyloidosis


Necrobiosis (e.g., rheumatoid nodules)


Crohn disease




Leprosy

The larynx is the second most common site in the head and neck after the sinonasal area to be involved by leprosy.15 Within the larynx, the lesions are painless and develop supraglottically and then progress to the glottis. The lesions may appear nodular and ulcerated, and infection can eventually lead to laryngeal stenosis. Histologically, the process is similar to that noted in the nasal area and is usually composed of a mixture of chronic inflammatory cells and large, foamy macrophages. Myocobacterium leprae (Hansen bacillus) may be identified by histochemical staining for acid-fast bacilli.


Fungal Infections

Fungal infections of the larynx are uncommon, are frequently associated with widespread disease, and are most often found in immunocompromised patients. Laryngeal histoplasmosis may present as either multiple nodular or ulcerated lesions.15,17 These may also appear somewhat granular and verrucoid. Patients frequently have involvement of the vocal cords with concomitant disease within the mouth.17 The microscopic appearance is variable. A mixture of acute and chronic inflammation is usually present with numerous large macrophages with abundant granular cytoplasm. Some cases may have well-formed caseating granulomatous inflammation and others may be devoid of granulomata. The overlying epithelium is often ulcerated; however, marked pseudoepitheliomatous hyperplasia may be present and should not be confused with squamous cell carcinoma. Although the organisms can frequently be seen on routine, hematoxlin and eosin (H&E)-stained material, silver or periodic acid-Schiff (PAS) staining also can be used to highlight their presence (Fig. 15.5, eFig. 15.7).

Extrapulmonary involvement by blastomycosis is common. When it affects the larynx, patients typically present with hoarseness, with or without coexistent pulmonary or cutaneous lesions.15,18,19 Laryngeal blastomycosis is typically described as erythematous, irregular, and granular lesions that may also appear verrucoid. Histologically, these lesions are characterized by pseudoepitheliomatous hyperplasia with mixed acute and chronic inflammation. Langhans giant cells are usually seen, together with intraepithelial microabscesses and granulomata, some of which may be suppurative (Fig. 15.6). The causative organism, Blastomyces dermatitidis, can usually be identified with H&E-stained material, or with silver or PAS stain. It characteristically demonstrates broad-based budding (eFigs. 15.8 and 15.9).

Rarely, Coccidioides immitis can involve the larynx.20,21 Patients with laryngeal infection almost always have coexistent pulmonary disease. For an unknown reason, most reported cases have affected blacks. Patients typically present with hoarseness and a sore throat. Grossly, the lesions most often involve the cords and typically appear granular and nodular. Frequently, the differential diagnosis included squamous cell carcinoma or tuberculosis. Histologically, pseudoepitheliomatous hyperplasia is often
seen with mixed inflammation and giant cells, with or without well-formed granulomata. The characteristic spherules and endospores of the organisms can be seen both by conventional H&E stain and with silver or PAS stains.






FIGURE 15.5 Intracellular organisms consistent with Histoplasma are seen in this case of laryngeal infection.






FIGURE 15.6 This case of laryngeal blastomycosis has numerous suppurative granulomata.


Other fungal organisms may also involve the larynx and infections secondary to Cryptococcus neoformans, Candida albicans, Aspergillus spp., Rhinosporidium seeberi, and Paracoccidioides have been reported (Fig. 15.7, eFig. 15.10).22,23,24,25,26 Each of these may be seen in immunocompromised patients with or without more widespread disease. Occasionally, they may present in apparently immunocompetent patients without evidence of disease elsewhere. Patients typically present with hoarseness and have granular and sometimes exophytic lesions involving the larynx. As with other fungal infections, pseudoepitheliomatous hyperplasia is often present (eFig. 15.11). A mixed inflammatory infiltrate is typically seen that can involve the epithelium. Fungal organisms may be identified on routine and special stains. A mucicarmine stain can be used to highlight the capsule of C. neoformans (eFig. 15.12).


Bacterial Infections

Bacterial infection of the supraglottic larynx and hypopharynx is now rare, thanks to vaccination for Haemophilus influenzae and Corynebacterium diphtheriae.27,28 Patients with infection by H. influenzae typically present with fever and difficulty breathing. Abundant edema is seen within the supraglottic larynx, especially involving the epiglottis.28 Tissue is rarely reviewed histologically but will show abundant acute inflammation. Patients with diphtheria have ulceration of the oral cavity, pharynx, and larynx with pseudomembrane formation. Histologically, the pseudomembranes contain fibrin, neutrophils, cell debris, and bacteria. The underlying stromal tissues are edematous with acute inflammation.27






FIGURE 15.7 Surface erosion with numerous pseudohyphae is seen in this case of laryngeal candidiasis.


Secondary and tertiary syphilis can rarely involve the larynx.15,23 Secondary syphilis is characterized by maculopapular erythema or condyloma latum. Histologically, secondary syphilis is characterized by a thinned epithelium or, conversely, epithelial hyperplasia (condyloma latum) with a dense lymphoplasmacytic infiltrate, sometimes with granulomas. Tertiary syphilis is characterized by gummas, destructive and painless necrotic lesions. Histologically, these are characterized by necrotizing, granulomatous inflammation. A lymphoplasmacytic vasculitis may be noted in both secondary and tertiary forms of disease. Spirochetes may be identified in earlier lesions with silver stains (Warthin-Starry, Dieterle, etc.).

The larynx is rarely involved by rhinoscleroma secondary to infection by Klebsiella rhinoscleromatis.15,29,30 Patients usually also have sinonasal disease; however, isolated laryngeal infection has been reported. The histologic features are similar to those of the sinonasal area (described in Chapter 13), and the disease is thought to proceed through exudative, proliferative, and sclerotic phases.
