Pathology of the Ear



Pathology of the Ear





Like the sinonasal tract, the ear has a rather complicated anatomy with multiple types of epithelium, adnexa, and close proximity to disparate structures. The different portions of the ear are affected by both similar and diverse pathologic processes. The auricle is covered by skin and is extensively sun-exposed. Not surprisingly, it frequently develops cutaneous malignancies. The inner and middle ear are involved by many of the same malignancies that affect the upper aerodigestive tract. In addition, distinct neoplasms such as middle ear adenoma and endolymphatic sac tumor are unique to these structures. This chapter discusses both nonneoplastic and neoplastic disease of the ear.


NONNEOPLASTIC DISEASE

Nonneoplastic diseases of the ear are more common than actual neoplasia; however, they are infrequently sampled and thus seldom seen by pathologists. While the infectious lesions are by far the most frequent of the nonneoplastic conditions, it is most important that pathologists recognize the lesions of the ear that form masses and mimic neoplasms. Some of these disease processes are specific to the ear, such as chondrodermatitis nodularis chronica helicis.


Congenital Abnormalities and Choristomas

Congenital abnormalities of the ear usually present in childhood. Accessory tragi arise from remnants of the first branchial cleft.1 These pedunculated lesions are typically less than 1 cm in size and most often are located just anterior to the true tragus. The lesions are either solitary or multiple and are sometimes bilateral. While they are generally not associated with other congenital abnormalities, some patients are also found to have midline abnormalities such as cleft lip or palate. Histologically, accessory tragi have all the components of the normal external ear. They are covered by a stratified squamous epithelium and the underlying dermis is replete with appendages (Fig. 16.1, eFig. 16.1).1 The stroma contains fibroadipose tissue and mature hyaline cartilage.

Other anomalies of the first branchial cleft include cysts, sinuses, and fistulas.2 Each usually occurs anterior to the tragus, similar to an accessory
tragus; however, their locations vary much more widely. Indeed, these lesions frequently involve the parotid gland and can be confused clinically with parotid tumors. Sinuses and fistulas often drain into the external ear canal or even the middle ear. First branchial cleft cysts, sinuses, or fistulas are akin to other branchial cleft abnormalities and are lined by ciliated columnar or stratified squamous epithelium surrounded by adnexal structures and lymphoid tissue.2 Unlike other branchial cleft abnormalities, first branchial cleft cysts sometimes contain cartilage. These remnants are frequently infected at the time of their discovery, and the epithelium is sometimes denuded or necrotic; abundant acute inflammation will then be present.






FIGURE 16.1 An accessory tragus.

Both glial and salivary gland choristomas are found in the middle ear.3,4,5,6,7,8,9 It has been noted by some that true glial choristomas may actually be very rare at these sites, and that most reported glial choristomas actually represent either encephaloceles or extruded brain tissue presenting as a middle ear lesion after other local disease processes such as cholesteatomas have led to the destruction of intervening temporal bone.3 Choristomas present in the middle ear behind an intact tympanic membrane and are histologically composed of either glial tissue or salivary gland tissue. The glial choristomas are composed of predominately astrocytes and neurofibrils.3,8 Salivary gland choristomas have a mixture of mucinous and serous glands with ducts (Fig. 16.2).6,7,9 Some amount of adipose tissue is often noted.

Congenital cholesteatomas resemble their acquired counterparts described below.10,11,12,13,14 They present in younger patients than acquired cholesteatomas and are much less common, representing less than 5% of
cholesteatomas. An intact tympanic membrane is usually but not universally present. The lesions are discovered either incidentally during otologic examination or because of unilateral hearing loss. Some believe that these lesions develop from epidermoid remnants found in the middle ear. Regardless, they are histologically identical to acquired cholesteatomas, and samples are composed of fragments of stratified squamous epithelium and keratin. A foreign body reaction is sometimes seen.






FIGURE 16.2 Salivary gland choristoma found in a middle ear biopsy of a cholesteatoma.


Infectious Disease

Infections of the external and middle ear are relatively common, but histologic sampling rarely is performed. They can be caused by a variety of organisms including viruses, bacteria, and fungi. Most disease is self-limited, although severe life-threatening infections sometimes develop, especially in immunocompromised patients.

Abscesses or furuncles of the external ear are usually associated with sebaceous glands and hair follicles and thus present within the auricle or outer canal.15,16 These are red, inflamed nodules that may be exquisitely painful. Although they are most often secondary to infection by Staphylococcus aureus, a number of bacteria can be linked etiologically to these pustules. Histologically, pockets of neutrophils and debris are surrounded by abundant acute and chronic inflammation, typically with some degree of fibrosis and granulomatous inflammation. Involved pilosebaceous units are usually seen.

Otitis externa, both benign and “malignant,” is most often caused by infection with Pseudomonas aeruginosa.15,17,18,19 Both forms of disease
represent variants of cellulitis. The benign or more common form develops most often in the lateral portion of the external auditory canal and may be secondary to predisposing factors such as local trauma and disruption of the ceruminal barrier. The disease develops most often in tropical climates and in humid weather. Swimming is a risk factor for the development of the disease. The “malignant” or necrotizing form is much more aggressive and typically involves the more medial portion of the external auditory canal. It occurs in older patients, many of whom are immunocompromised secondary to diabetes mellitus. These infections may spread along tissue and fascial planes, along cranial nerves and vessels, and eventually involve the parotid gland, surrounding bone or brain. Thrombophlebitis of the cavernous sinus even develops in some cases. Histologically, the findings correspond to the extent of the infection. Edema and acute and chronic inflammation are seen throughout the involved soft tissue. Ulceration, necrotizing vasculitis, and tissue necrosis are all seen as the process worsens.

As with otitis externa, otitis media is very unlikely to be sampled. This extremely common disease of childhood presents with ear pain and bulging, erythematous, or exudative tympanic membranes on otologic examination.16 Recurrent and chronic infections secondary to blockage of the eustachian tubes sometimes lead to complications, including cholesteatoma.20 Causative agents include bacteria, such as Streptococcus pneumoniae, Haemophilus influenzae, and Moraxella catarrhalis, along with various upper respiratory tract viruses.16 Sampling shows a nonspecific acute and chronic inflammatory infiltrate within the epithelial and stromal tissues. Rarely, Mycobacterium tuberculosis infects the middle ear and, when sampled, a granulomatous reaction is seen.21 Finally, it should be noted that otitis media in adults is frequently associated with neoplasia.

Viral infections sometimes involve the external ear and tympanic membrane (myringitis). The ear canal and tympanic membrane can be involved by Varicella zoster (Ramsay-Hunt syndrome) and Herpes simplex virus.19,22 The clinical and pathologic findings are identical to those seen at other sites. The telltale nuclear inclusions within the squamous cells of the vesicles or ulcerated areas should lead one to the correct diagnosis. Occasional hemorrhagic vesicles can be seen on the external tympanic membrane in cases of influenza.16

Fungi rarely infect the squamous epithelium of the external ear (otomycoses).15,22,23,24 Most of these infections are caused by Aspergillus or Candida species. In general, these infections present as typical cases of otitis externa, and it is estimated that 2% of cases of otitis externa are caused by fungi. Histologically, the squamous epithelium is thickened with parakeratosis and focal collections of intraepithelial neutrophils (Fig. 16.3). Hyphal and yeast forms are then found within the parakeratotic plaques. Subepithelial chronic inflammation is also typically noted. The fungi should not extend into the subepithelial tissues in uncomplicated cases of otomycosis. Deeper infections by a number of organisms such as cryptococcus and blastomyces are rare but have been reported.







FIGURE 16.3 Parakeratotic plaque with intraepithelial neutrophils seen in a patient with otomycosis.


Inflammatory and Reactive Conditions and Other Abnormalities

The lengthy designation chondrodermatitis nodularis chronica helicis describes a painful, inflammatory lesion of the external ear.25,26,27 The lesion occurs somewhat more frequently in older men and typically involves the outer portion of the helix, but any portion of the auricle may be involved. It most often presents as a painful, solitary nodule that is less than 1 cm in size. A surface crust is typically seen, and clinicians often believe the lesions are malignant prior to biopsy. The pathogenesis of the condition is uncertain. Most believe it to arise from localized ischemia related to chronic conditions such as sun damage and repeated pressure-related trauma. This process is benign and is typically cured by limited local resection.

Histologically, the centrally ulcerated and crusted area is surrounded by thickened and parakeratotic squamous epithelium.25,26,27 The fibrinous debris of the ulcer base extends centrally to the perichondrium and auricular cartilage and is surrounded by granulation tissue and acute and chronic inflammation. Some degree of erosion of the cartilage is often seen with surrounding necrosis and basophilia (Fig. 16.4, eFigs. 16.2 and 16.3). Reactive changes such as stromal cellular atypia and fibrosis can be seen.

Idiopathic cystic chondromalacia, also known as pseudocyst of the auricle, typically presents as a swelling of the auricle in young to middle-aged adults.28,29 Although any portion of the auricle can be involved, the helix is the most commonly affected site. The pathogenesis of these lesions
is unknown, but as with chondrodermatitis nodularis chronica helicis, trauma may play some role. Histologically, these are pseudocystic spaces within the auricular cartilage with surrounding normal cartilage, degenerated cartilage, or granulation tissue (Fig. 16.5, eFig. 16.4).






FIGURE 16.4 An ulcer extends to the auricular cartilage in this case of chondrodermatitis nodularis chronica helicis.






FIGURE 16.5 A pseudocyst was found in the auricular cartilage consistent with idiopathic cystic chondromalacia.


As was discussed in the chapter describing nonneoplastic disease of the larynx (Chapter 15), relapsing polychondritis is a rheumatic disease characterized by episodic and progressive inflammation of cartilage.30,31 The ears are often affected and involvement is typically bilateral. Diagnosis requires a combination of clinical and pathologic findings. Histologically, the cartilage will typically appear necrotic or degenerated with surrounding acute and chronic inflammation.

Kimura disease is a chronic inflammatory condition that frequently involves the head and neck at or just behind the ear.32,33,34,35,36 Patients are more often men, and the disease appears to be much more common in Asian populations. The lesions typically present as painless masses averaging 2.5 cm in size and located deep to the dermis with associated regional lymphadenopathy and parotid involvement. Although the pathogenesis is unknown, patients are frequently noted to have peripheral eosinophilia and elevated serum concentrations of IgE.

Histologic sections of Kimura disease usually show some degree of residual lymph node architecture with follicular hyperplasia and well-formed mantle zones (Fig. 16.6).32,33,34,35 The inflammatory infiltrate most often extends into the perinodal soft tissues and capsular and stromal fibrosis are typically present. Eosinophilic folliculolysis is usually seen with necrosis and proteinaceous debris noted within the germinal centers. Abundant eosinophils are also present in the interfollicular areas, sinusoids, and perinodal tissue, and these frequently aggregate into small eosinophilic microabscesses (eFigs. 16.5 and 16.6). An increased number
of vessels is frequently noted, as is a postcapillary venular proliferation. Immunohistochemistry supports the diagnosis of a reactive process and testing for Epstein-Barr virus is usually negative.






FIGURE 16.6 Kimura disease with follicular hyperplasia, fibrosis, and an eosinophilic abscess.

Kimura disease should be distinguished from angiolymphoid hyperplasia with eosinophilia (epithelioid/histiocytoid hemangioma) as the two are distinct clinicopathologic entities (Table 16.1).32,33,34,35 Kimura disease occurs more frequently in Asians and men, more often is deep to the dermis, and is associated with adenopathy and salivary gland involvement, increased serum IgE levels, and peripheral eosinophilia. Angiolymphoid hyperplasia with eosinophilia occurs equally in all races, is more common in women, presents as a superficial papule, and is not associated with peripheral eosinophilia, increased serum IgE levels, or adenopathy. In Kimura disease, the vascular component is much less prominent than it is in angiolymphoid hyperplasia with eosinophilia, and the endothelial cells are typically flattened rather than epithelioid.

Keloids of the ear resemble those seen throughout the rest of the body, both clinically and pathologically.37,38 As such, they develop more frequently in black individuals and often arise after local trauma, such as ear piercing. They present as firm, pink nodules, usually covered by an intact epithelium. The histologic features are rather distinct with thick, eosinophilic bands of collagen present throughout the dermal tissue, often obliterating adnexal structures and flattening the surface epithelium (Fig. 16.7, eFig. 16.7). As such, the lesions appear quite hypocellular and are composed predominately of collagen with occasional intermixed fibroblasts.








TABLE 16.1 Clinicopathologic Features of Kimura Disease and Angiolymphoid Hyperplasia With Eosinophilia
























Kimura Disease


Angiolymphoid Hyperplasia with Eosinophilia


Patients


More likely to affect Asians and men


No racial predilection; occurs slightly more often in women


Clinical


Associated with peripheral eosinophilia and elevated IgE levels


Not associated with peripheral eosinophilia or elevated IgE levels


Gross


Deep, subcutaneous lesions with local adenopathy and salivary gland involvement


Superficial dermal papules that may itch or bleed; no local adenopathy or salivary gland involvement


Histology


Inflammatory infiltrate with follicular hyperplasia and eosinophils, fibrosis and postcapillary venular proliferation


Abundant vascular proliferation with plump, epithelioid endothelial cells; background lymphoplasmacellular infiltrate with eosinophils and fibrosis








FIGURE 16.7 A keloid.

Keratin accumulation in the external ear canal can cause obstruction either secondary to the keratin itself or secondary to the body’s response to the keratin. Some individuals apparently have impaired lateral extrusion of external canal keratin, which then accumulates and plugs the canal (keratosis obturans).39 The keratin in such cases actually accumulates to such a degree as to widen the canal and cause pressure ulceration of the surrounding epithelium. Secondary infections are common. The histologic features are as unexciting as one would expect. There is abundant keratinous debris, sometimes with cholesterol clefts, inflammation, and evidence of epithelial ulceration (Fig. 16.8; eFig. 16.8). Keratinous cysts of the external ear can also cause obstruction. As with the more common middle ear lesions, they are called cholesteatomas here.39 Histologically, they are cystic structures, lined by a bland, stratified squamous epithelium. With rupture of these cysts or through ear canal trauma, keratin can come into contact with the stroma and abundant foreign body reaction can be formed (keratin granulomas).39,40 These further lead to obstruction of the canal and can cause hearing loss and pain.

Acquired cholesteatomas of the middle ear are nonneoplastic masses caused by the production of keratin by stratified squamous epithelium.11,13,27,41,42 Given the small volume of the middle ear, one can imagine that very small lesions easily result in clinical problems. Acquired cholesteatomas are distinguished from congenital cholesteatomas through assessment of the tympanic membrane. As acquired cholesteatomas are believed to result from severe otitis media or, rarely, trauma, and entry of squamous epithelium from the external ear into the middle ear, they are typically associated with ruptured tympanic membranes. Clinically, acquired cholesteatomas appear white and pearly. Histologically, they are composed
of keratin and stratified squamous epithelium that is sometimes fragmented (Fig. 16.9). They occasionally present as intact cystic structures (eFig. 16.9). Calcification, inflammation, and foreign body reaction are also commonly present.






FIGURE 16.8 Abundant keratin was removed from the external auditory canal of a patient with apparent keratosis obturans.






FIGURE 16.9 Resections of acquired cholesteatomas show fragmented squamous epithelium and keratinous debris.


Chronic otitis media is sometimes associated with middle ear cholesterol granulomas.43 These yellow, nodular lesions are believed to be secondary to hemorrhage. Histologically, they are composed of red blood cells, hemosiderin-laden macrophages, cholesterol clefts, and a foreign body reaction. It is important that these lesions not be mislabeled as cholesteatomas as they are not locally aggressive.

Chronic otitis media is also associated with the formation of an inflammatory polyp (aural polyp) of the middle ear.44 These nonneoplastic lesions frequently extend through the tympanic membrane into the external auditory canal. They are polypoid masses of granulation tissue and inflamed stroma (Fig. 16.10, eFig. 16.10). Edema, fibrosis, foreign body reaction, hemosiderin-laden macrophages, and cholesterol granulomas all may be present within the body of the polyp. The surface epithelium is often eroded but if present is either ciliated columnar or squamous. Inflammatory polyps may be associated with cholesteatomas or neoplasms.

Most masses composed of mature bone within the ear canal are classified as osteomas or as bony exostoses.45,46 External ear osteomas are more common in men, occur over a broad age range, and present as solitary, pedunculated bony lesions attached to underlying bone. Bony exostoses are broad-based, often bilateral lesions of the external auditory canal that are also more common in men and often present with obstructive hearing loss. Both lesions are composed of mature, lamellar bone present beneath the intact squamous epithelium of the canal (Fig. 16.11, eFig. 16.11). Osteomas have been noted to have larger interlamellar spaces. These lesions are difficult to confuse with other entities although some have noted that lesions such as fibrous dysplasia should be excluded.






FIGURE 16.10 Aural polyps are composed of granulation tissue.







FIGURE 16.11 An osteoma of the external auditory canal.

Many other inflammatory processes affect various or all portions of the ear. The auricle can be easily traumatized, sometimes chronically such as with the ear pieces of glasses (spectacle frame acanthoma or granuloma fissuratum).47 Chronic trauma also sometimes leads to calcification or ossification of the ear lobe (petrified auricle).48 Malakoplakia and xanthomas have been reported in the ear.49,50 IgG4-related sclerosing lesions have been reported in the ear.51 Ulcers secondary to cold and humid weather (chilblains) have been reported.52 Elastic nodules can form on the external ear secondary to severe sun damage.53 The external auditory canal may exhibit a foreign body reaction to any of the many things that are placed within it and myospherulosis, akin to that seen in the sinonasal area, has been seen.54,55 Finally, systemic processes, such as sarcoidosis and Wegener granulomatosis, sometimes involve portions of the ear.56


NEOPLASTIC DISEASE

As mentioned in the chapter introduction, neoplasms of the ear include dermal-type tumors, neoplasms also seen in biopsies of the upper aerodigestive tract, and occasional pathologic entities specific to the area. A nice summary of the frequencies of these neoplasms, based on the Armed Forces Institute of Pathology (AFIP) experience, was originally published in the second edition of the AFIP fascicle concerning neoplasms of the upper aerodigestive tract and ear (Tables 16.2 and 16.3).57 Most of the lesions in this area are biopsied prior to definitive surgical resection and thus correct diagnosis is essential.









TABLE 16.2 Neoplasms of the External Ear57






























Neoplasm


Percentage


Squamous cell carcinoma


34


Basal cell carcinoma


31


Melanocytic neoplasia


11


Osteoma


3


Ceruminous neoplasia, benign


3


Ceruminous neoplasia, malignant


3


Atypical fibroxanthoma


1


Others


14



External Ear and External Auditory Canal

The majority of neoplasms arising in the external ear and auditory canal occur on the auricle and are dermal in nature. Because of its location and exophytic nature, the auricle is subject to abundant sun exposure. As such, most of the neoplasia that develops here is secondary to sun damage and is identical to sun damage-induced dermal neoplasia elsewhere.

Seborrheic keratoses are not uncommonly found on the external ear or within the ear canal.58,59 They appear here, like elsewhere, as brown irregular patches that look to have been “stuck on” to the skin of older adults. These lesions can vary in size but are usually approximately 1 cm. Occasionally, they appear somewhat atypical and raise clinical concerns for melanoma. These are, however, benign tumors that only rarely recur after surgical removal. Histologically, the epidermis in thickened; the bases of the lesions are smooth and do not extend more deeply than the
surrounding uninvolved epidermis. The epithelium is composed of proliferating and bland basal cells, and invaginations of the surface keratin lend the lesions their well-known pseudohorn cysts (Fig. 16.12). Inflamed lesions may show more individual cell keratinization and some lesions have basilar pigmentation.








TABLE 16.3 Neoplasms of the Middle Ear and Temporal Bone57

































Neoplasm


Percentage


Schwannoma


41


Paraganglioma


15


Middle ear adenoma


9


Squamous cell carcinoma


5


Metastasis


5


Langerhans cell histiocytosis


2


Rhabdomyosarcoma


2


Choristoma


1


Others


20







FIGURE 16.12 Frequent pseudohorn cysts are seen in most seborrheic keratoses.

Squamous cell carcinomas of the ear often develop on the auricle and are related to actinic damage.60,61,62,63 Many thus develop in older, fair-skinned men. Some squamous cell carcinomas of the ear develop in the external auditory canal. While these also occur in older individuals, they appear to be not related to sun damage and may instead be associated with chronic otitis externa. They have been found to be more common in women. Symptoms depend on the location of the tumor. Tumors appear as painful mass lesions that are sometimes ulcerated. Those of the external auditory canal often present with otorrhea.

Squamous cell carcinomas share the same histologic features regardless of site (see Chapter 4).60,61,62 Those of the ear show variable differentiation or maturation with infiltrating irregular nests of atypical squamous cells (Fig. 16.13, eFig. 16.12). Squamous cell variants are also seen associated with the ear, especially spindle cell or sarcomatoid carcinomas (see Chapter 5). Those with a basaloid morphology are better termed “basal cell carcinomas” when they occur in sun-exposed skin (see below). Background actinic change with solar elastosis will be seen with those tumors originating in sun-exposed skin. As with squamous cell carcinomas seen at other sites, the differential diagnosis includes benign squamoproliferative processes, especially those lesions associated with pseudoepitheliomatous hyperplasia. Careful attention to architectural and cytologic
atypia should allow for the distinction of most of these lesions. Spindle cell carcinomas need to be distinguished from melanomas and mesenchymal neoplasms. This distinction often rests with the use of immunohistochemistry and has been discussed in Chapter 5.
